Specification
2 Seat Low speed | 2 Seat High speed | |
Color | RED,PINK, WHITE,YELLOW,ORANGE, GREEN, BLUE, BROWN, PURPLE | |
Top speed(Km/h) | 45 | 80 |
Gradeability | 0.2 | 0.2 |
Charging time | 6-8hours | 6-8hours |
Range(km) 40km/h | 140 | 80~100 |
Model | JY7221-ZQR | JY7222-ZQR |
Overall dimensions(L*W*H)mm | 2245*1290*1570 | 2245*1290*1570 |
Wheel base(mm) | 1500 | 1500 |
Wheel track(mm) | 1100/1090 | 1100/1090 |
Min.ground | 150 | 150 |
Curb weight(kg) | 635(with battery) | 643(with battery) |
Seating capacity | 2 | 2 |
Motor type | AC motor | AC motor |
Kw Rated Power | 3.5 | 7.5 |
Rated Voltage(V) | 60 | 72 |
Battery | Maintenance-free lead acid battery | Maintenance-free lead acid battery |
Battery quantity | 5 | 6 |
Battery capacity | 12V 120Ah | 12V 100Ah |
Charger type | Car charger | Car charger |
Charging voltage(V) | 220 | 220 |
Gears | Auto gear | Auto gear |
Gear shift type | Single reduction | Single reduction |
Differential case | Yes | Yes |
Driving type | Rear-wheel-drive | Rear-wheel-drive |
Front suspension | McPherson | McPherson |
Rear suspension | Trailing-Arm Independent | Trailing-Arm Independent |
Body structure | Load bearing frame | Load bearing frame |
Service brake | Four wheel disc brakes | Four wheel disc brakes |
Parking brake | Handbrake | Handbrake |
Tyre size | 145/70R12 | 145/70R12 |
